Barrier Blocks
Series 176
.375 Density, 5-40 x 3/16"
BH Screw, Dip Solder,
Single Row
Electrical Characteristics
Voltage Rating: 250 Volts maximum
Current Rating: 15 Amps maximum
Maximum Watts Per Terminal: 3750
Mechanical Characteristics
Maximum Wire Size: 16 AWG
Recommended Tightening Torque: 16 lb.-in.
Dimensions
L
M
Ordering Information
With Mounting Ears
No. of
Terminals
2
3
4
5
6
7
8
9
10
Catalog No. Catalog No.
.125 Tail Lgth .184 Tail Lgth
2-176-2 2-176-3
3-176-2 3-176-3
4-176-2 4-176-3
5-176-2 5-176-3
6-176-2 6-176-3
7-176-2 7-176-3
8-176-2 8-176-3
9-176-2 9-176-3
10-176-2 10-176-3
“M”
Dimension
1.125
1.500
1.875
2.250
2.625
3.000
3.375
3.375
4.125
“L”
Dimension
1.469
1.844
2.219
2.594
2.969
3.344
3.719
4.094
4.469
Without Mounting Ears
No. of
Terminals
2
3
4
5
6
7
8
9
10
11
12
Catalog No. Catalog No.
.125 Tail Lgth .184 Tail Lgth
2-176-2A 2-176-3A
3-176-2A 3-176-3A
4-176-2A 4-176-3A
5-176-2A 5-176-3A
6-176-2A 6-176-3A
7-176-2A 7-176-3A
8-176-2A 8-176-3A
9-176-2A 9-176-3A
10-176-2A 10-176-3A
11-176-2A 11-176-3A
12-176-2A 12-176-3A
2-27
“L”
Dimension
.719
1.094
1.469
1.844
2.219
2.594
2.969
3.344
3.719
4.094
4.469
Marketed exclusively through distribution.
Call Toll Free: 1 (800) 323-9612
